| Application | 24 Vac systems; Gas, Oil, Electric Warm Air | Hot water Coil; Gas, Oil, Electric Hydronic | Steam / Gravity Systems | Dual Fuel |
|---|---|
| Product Features | Dual fuel and aux heat lockout | Hot water systems including Series 20 and hot water coil. | Control a humidifier, dehumidifier, or ventilator. | Wired outdoor sensor or Internet weather. | Wireless indoor temperature, humidity, and motion sensors. | Geofence capable. | electable ranges stops: min and max heat and cool. | 5-year warranty | ENERGY STAR® Certified |
| Thermostat Type | Programmable | Low Voltage | Digital | WiFi |
| Approvals and Standards | FCC: 47 CFR § 15.19 (a)(3), 47 CFR § 15.21 (USA only), & 47 CFR § 15.105 (b). IC REGULATIONS: RSS-GEN |
| Stages | Up to 3 Heat/2 Cool Heat Pump Systems | Up to 2 Heat/2 Cool Conventional Systems |
| Smart Home Integration | Yes |
| Display Size | 7.27 sq in |
| Touchscreen | Yes |
| Display Language | Display selectable for English, French, or Spanish |
| Modes of Operation | Heat | Cool | Emergency Heat | Dehumidify | Humidify |
| Programming Features | Uses Sensors for Priority Scheduling | Geofencing |
| Program Type | 7-Day Programmable | Manual / Not Programmed | 5-1-1 Programmable | 5-2 Programmable | 1 Week |
| Energy Star Certified | Yes |
| Alerts and Reminders | Battery Replacement | Dehumidifier Filter | EAC Post-filter | EAC Pre-filter | Filter Change 1 | Filter Change 2 | Heat Pump Failure | Humidifier Pad (through app) | UV Bulb 1 | UV Bulb 2 | Vent Core | Vent Filter | WiFi No Internet |
| Heat-Cool Changeover | Auto | Manual |
| Power Supply | Battery | Hardwired |
| Warranty | 5 Years |
| Occupancy Sensor | With some models |
| Includes | T10 Smart Thermostat | UWP Wall plate | Decorative Cover Plate | Screws and anchors | Thermostat literature | RedLINK 3.0 indoor sensor |
| Communication Type | WiFi |
| WiFi | Yes |
| WiFi Specifications | 802.11b | 802.11g | 802.11n | 2.4GHz range | 5GHz range |
| Z-Wave | No |
| Radio Frequency | 900 Mhz |
| Radio Frequency Transmitting Range (Max) | 200 ft |
| RedLINK | Yes |
| Color | White |
| Sensor Type | Thermistor |
| Ambient Operating Temperature (Max) | 102 °F | 39 °C |
| Ambient Operating Temperature (Min) | 37 °F | 2.8 °C |
| Operating Relative Humidity (Max) | 90% Non-condensing |
| Operating Relative Humidity (Min) | 5% Non-condensing |
| Backlight Options | Adjustable |
| Fan Function | On | Auto | Circulating |
| Compatible Sensor | Discharge Air Temperature Sensor | Outdoor Temperature Sensor | Room Temperature Sensor |
| Demand Response | Yes |
| Cycle Rate | Heating Adjustable 1,3,5,9 CPH |
| Electrical Connection Type | UWP Mounting System |
| Humidity Set point (Max) | 90% RH |
| Humidity Set point (Min) | 0% RH |
| Mounting Type | UWP Wall Plate |
| Operating Voltage (Max) | 30 V AC |
| Power Supply Frequency | 50 Hz | 60 Hz |
| Set point Temperature (Max) | Heat: 90 °F | Heat: 32 °C | Cool: 99 °F | Cool: 37 °C |
| Set point Temperature (Min) | Heat: 40 °F | Heat: 4.5 °C | Cool: 50 °F | Cool: 10 °C |
| Shipping and Storage Temperature (Max) | 120 °F | 49 °C |
| Shipping and Storage Temperature (Min) | -20 °F | -29 °C |
| Mounting Location | Wall |
| Switch Type | Relay |
| Compatible App | First Alert App | Resideo App |
| Product Height | 4.92 | 125 |
| Product Width | 3.7 | 94 |
| Product Depth | 0.95 in | 24 mm |
| Features | Backlit Display | Filter Change Reminder | Geofencing | Room Sensors | Smart Home Enabled | Touchscreen Display | WiFi | Indoor Air Quality Control | ENERGY STAR Certified | Utility Rewards | Humidity Sensor | Temperature Sensor | Smart Alerts | Adaptive Intelligent Recovery |
The T10+ Pro Smart with RedLINK® Room Sensor allows homeowners to prioritize comfort in the rooms that matter most, using time-based scheduling, motion detection or geofencing. Priority settings optimize comfort by using sensors in the areas of the house where people are.
- Smart WiFi thermostat with RedLINK® technology
- Color graphical LCD touchscreen display
- Configurable daytime and nighttime backlight settings
- Up to 3H/2C Heat Pump or 2H/2C Conventional
- T10+ models can be used with slab sensor
- Up to 4H/2C Heat Pump or 3H/2C Conventional (T10+ with EIM)
- Controls Humidification, Dehumidification, or Ventilation (all three with T10+ and EIM)
- Demand Response Program availability
- On-screen menus with familiar installer setup (ISU) steps
- Optional geofencing
- Flexible programming (7, 5-2, 5-1-1, 1, Off)
- Location-based temperature control
- Dual Fuel compatible
- Connects with our app
- Works with Amazon Echo, Google Assistant, and more
- ENERGY STAR® certified
- Supports WiFi 802.11 B/G/N 2.4 and 5 GHz
- Dry contact alerts including system shut down with full drain pan alert
