| Stages | 3 Heat/2 Cool |
|---|---|
| Number of Original Zones | 4 |
| Application | Zoning |
| Warranty | 5 Years |
| Includes | HZ432 Zone Control Panel|AT140 Transformer|C7735A Discharge Air Temperature Sensor |
| Product Height | 13.42 |
| Product Length | 8 |
| Product Width | 1.86 |
| Color | Gray |
| Auto Changeover | Yes |
| Checkout Procedure | Yes |
| Compatible Sensor | Discharge Air Temperature Sensor|Outdoor Temperature Sensor |
| Display Type | Not Applicable |
| LED Functions | Stage of heat and damper state |
| Power per Zone | 28.8 VA at 100 °F|16.8 VA at 160 °F|28.8 VA at 38 °C|16.8 VA at 71 °C |
| RedLink Specifications | THM4000 Wireless Adapter Module required |
The kit comes complete with the HZ432 Zone Control Panel, AT140 Transformer and C7735A Discharge Air Temperature Sensor. A fit for any smart home, this control panel works with conventional, heat pump or dual fuel applications. With intuitive, easy-to-follow steps, The TrueZONE® HZ432 Panel offers easy professional installation with a digital display will guide you through the install process. You'll get confirmation that the panel is operating properly before you ever leave the job site. Common-sense LEDs indicate which zones are calling and what stage they're calling for. At only 8 inches wide, the panels can be mounted on the return duct, studs or the wall next to the system.
- Get through installation quickly with four easy steps and a digital display that uses plain language to guide the installer
- Variable-speed fan
- Controls dual fuel
- Compatible with heat pump
- Includes resettable fuse
- Thermal fuse with auto-reset protection on each zone
